Description
Frame: M5 alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
Seat Binder: Alloy, 38.6mm
Rear Shock: X-Fusion 02 Pro RL, Ride Dynamics Trail Tune, rebound adjust, lockout, 210x55mm
Fork: RockShox, Psylo Silver, Motion Control Damper, 15×110 axle, 44mm offset, S1:150mm of travel, S2-S6:160mm of travel
Front Brake: SRAM DB6, 4-piston caliper, hydraulic disc
Rear Brake: SRAM DB6, 4-piston caliper, hydraulic disc
Shift Levers: SRAM NX Eagle, trigger, 12-speed
Rear Derailleur: SRAM NX Eagle, 12-speed
Cassette: SRAM NX Eagle, 12-speed, 11-50t
Chain: SRAM NX Eagle, 12-speed
Crankset: SRAM NX Eagle, DUB, S1-S3:165, S4-S6: 170mm, 55CL, 32T
Bottom Bracket: SRAM DUB Threaded Wide
Rims: Specialized Alloy, Tubeless Ready, 29mm internal width, 28h
Front Hub: Specialized alloy front hub disc, sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
Rear Hub: Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 28H, HD Steel Fhb
Spokes: Stainless, 14g
Front Tire: Butcher, GRID TRAIL casing, Gripton T9 compound, 29X2.4
Rear Tire: Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, TLR, S1-S2: 27.5×2.4, S3- S6: 29×2.4″
Inner Tubes: Standard, Presta Valve
Stem: Alloy Trail Stem, 35mm bar bore
Handlebars: Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
Grips: Specialized Trail Grips
Saddle: Body Geometry Bridge Saddle, steel rails, S1-S2:155mm, S3-S6:143mm
SeatPost: TranzX dropper, 34.9mm, S1: 125mm, S2: 150mm, S3: 175mm. S4-S6: 200mm
SWAT: Internal SWAT downtube storage
Product ID: 291350
Weight: 16.79 kg (37 lb, 0.2 oz)
Weight Size: S4
